Leadership vs Management
Leadership and management these two are often used interchangeably but are they interchangeable? Do we consider all managers to also be leaders and are all leaders managers? While the best managers will have traits of a good leader and visa-versa these two roles are not always synonymous. First thing we will want to do is to look at these roles individually and understand what the goal is each of these roles and how these roles interact with those around them.
Managers and Management
Management tends to a fluid role filling gaps as needed to make sure objectives and goals are met. In order to make sure goals are met managers often need to do following:
Planning: Since manager’s are tasked to accomplish a task within a certain timeline, resources, budget, and other constraints managers must have to ability to sit down and consider the tasks that have to be performed to accomplish the goal. These tasks also have to be accomplished within a certain time-frame and budget. This where you need to start answering the questions:
- What steps need to happen in order to complete the tasks?
- How much time does each step take?
- How many tasks can be executed in parallel?
- Which steps incur the most risk?
- How can address each risk?
- Are there any holidays, blackout days, or vacations overlapping with the schedule?
- Can the team maintain the pace required for duration of the task / project?
- Along many more questions..
While larger and long-term tasks / projects may have a dedicated or team of project managers, each manager is usually assigned or responsible for a particular domain which requires that manager to have deep understanding of their knowledge domain in order to deliver and plan for success.
Maintaining control and rationalizing: This can be a tricky one, as managers are responsible for delivering value to the business within the agreed upon timeline and budget a certain level of control must be maintained. Balancing how much control is required over the given situation without crossing a line is where it gets tricky. Managers that maintain too much control come off as micro-managers where-as having too little control are accompanied by its own set of issues. Some challenges includes:
- Maintaining progress to meet dealines
- Confirming people are where and when they need to be
- Staying ahead of gates, blockers and issues
- Operating within a budget
Setting goals and developing the team: As managers you are typically managing people and when you are managing people it is important to make sure goals and a progression is defined. Most people want to be challenged so that they can continue to grow.
- Where does this team member see themselves in the future?
- Is there a development plan to support this team member meet his future plans?
- Is the goal clearly defined and understood by everyone involved?
When it comes to goal setting and development plans there are many different things to consider these are just a couple of points (Maybe we will cover this more in a future post).
Leaders and Leadership
Where managers are focused on the objectives, the team, and delivering to the business; leaders on the other hand tend to be focused on a longer term impact to the business: developing a vision, inspiring new ideas and creating change while empowering those around them.
Motivate and Inspire: As a leader you want to provoke new ideas and out-of-box thinking, the best way to accomplish that is to inspire and motivate those around you.
- Brining a good energy to the team, room, or meeting
- Making sure everyone has a voice and is able to bring their ideas to the table
- Create a space that these ideas can be presented without fear or criticism, ridicule, or negativity
Ethical Champion: In order to empower and align those around you as a leader you must be trust-worthy and act with integrity. As you develop a rapport with those around you, your actions will convey your intentions and if your intentions / ethics are questionable you may find that people may not be upfront with you and if the team can’t be upfront with you then their will struggles in realizing and gaining support for a long-term vision. Leaders are those people that people may turn to when they hit challenge. Think about, the last time you hit a tough spot who did you turn to? Do you always report to a you direct manager or is there another peer you turn to for opinions, why do you go this person?
Setting a direction: Leaders are usually looking ahead toward long-term goals, these may involve changes to corporate culture or technology.
- Building on the last two sections, as leaders gain the trust of those around them and continue to motivate / inspire those around they are able to influence the direction forward. Now, Influence can be good or bad, in the association of leadership we assume this influence is designed to be positive. After all our leaders are ethical and looking for the best interest.
- When you are trying to change direction, you need to involve those that will be impacted by change. Soliciting ideas and inspiring the team come up with creative ways on how they can be a part of the upcoming change and how can the upcoming change be accomplished. This allows the team to be part of the vision allowing more people to buy in to the idea thus improving your chances of success.
I’ll provide a couple links below to two different podcast. These are podcast I have been subscribed to for many years now, one is focused on management and the second focused on leadership. I found these very insightful as they cover many different aspects of management and leadership:
The Look and Sound of Leadership
Long time readers will know my background originates from IT engineering, specifically network engineering. These leadership and management tid-bits are from my first hand experience, I do not have a business degree. Feel free to drop a comment to provide your thoughts and insight.
Wireshark tid-bit: Looking for the smoking gun
It’s not always the network which is at fault but it is usually the network that is the assumed culprit. Wireshark can be a vital tool when troubleshooting difficult scenarios or prove that the network is not root cause. The purpose of this post is to ask questions and promote out of the box thinking when troubleshooting with Wireshark. Some common problems:
- The network is slow / This file transfer is slow
- My application responds after X seconds
- This application or agent is not working
These are very broad problem statements and depending on how familiar you are with the configurations and infrastructure, these can sound like daunting tasks to troubleshoot. At least until we start asking more questions and begin gathering the information we need to start troubleshooting. On occasion it is easier to capture packets on the source and destination endpoints then see what the packets tell us, will the packet capture align with the problem or will the packets point us in another direction?
When using Wireshark to troubleshoot such a board and undefined problem, where do you start? Wireshark is great at collecting details, Wireshark also presents all this information to us in an organized and digestable fashion. It’s up to us as network professionals to solve the mystery. Next up we’ll discuss some key items that will help expedite the troubleshooting process and make you more comfortable performing and reading packet captures. We will also ask some thought provoking questions to involve not just network-related technologies and issues.
Capture points and filtering options
The capture point is the foundation of your upcoming analysis. If you are not capturing at the correct spot (or spots) any future protocol analysis will either make the troubleshooting process more difficult and time consuming or you may find yourself going down the wrong path. It is always a good idea to review and understand the traffic flow which you are troubleshooting. Then ask yourself, will traffic be passing through my capture point? Could this traffic flow take another network path? Could another technology such as Virtual Port-Channel (vPC), Virtual-Chassis, load-balancers, load-sharing, ACLs (it can become quite a large list) be causing traffic to flow in another direction or drop the traffic flow all together? Depending on the size of the infrastructure is it possible to walk the path of the packet, following MAC, ARP, and routing tables?
Capturing at the right point is half of the battle, the next big question is what kind of capture filter do you need? Should you just capture everything passing through the interface in question? Some items to consider:
- If you perform an unfiltered capture and capture all the details:
- Will you create a performance bottleneck? Packet capturing can be resource intensive impeding network performance for production traffic flows.
- Will the packet capture be usable? The larger the packet capture the more time it takes to filter and analyze. You need to start filtering the conversation at some point either pre- or post- capture. Having all the data is great but will it be helpful?
- If you do decide to filter your capture what is your criteria?
- Source and Destination are always valuable but will that show you the entire picture? Will you see DNS resolution? Do you need to be aware of any HTTP redirects?
Timestamps
Being mindful of the timestamps logged in a packet capture, this information can help identify a wide array of different issues. Wireshark captures multiple timestamps, like almost every other field in the packet you can turn that field into a column this allows you to quickly identify gaps in time. You can take this a step further by marking a ‘reference’ packet allowing you to see the time delta from the reference packet. This can be useful when determining how long a requests takes or how long it takes a TCP handshake to complete.
e.g.: Why did the application server take 32 seconds to start transferring data? What was occurring during that 32 second gap? Perhaps there was a delay in receiving traffic from a backend database? Did you capture the backend flow too? Typically when a database is waiting on a transaction to complete you may see ‘keep-alive’ packets allowing the TCP connection to remain open/active while backend tasks are being performed. If you are troubleshooting a performance issue and see ‘keep-alive’ packets your next step may be to understand why the request is taking so long. Continuing with the database example, does a query need to be updated? Is the database fragmented? Does the server need additional resources (CPU/Memory/Disk/etc)?
Source and destination details
Don’t discount the source and destination details of the conversations. These details allow you to confirm the traffic is flowing the way you expect it to be going.
- MAC address – Does the source and destination MAC addresses line up with the expected network interfaces? Could the traffic be going a different path? Is there a misconfiguration causing traffic to flow over a different interface?
- I have seen colorful packet captures when LAG is enabled on the server-side but not on the network side. (This was not 802.3ad LACP)
- Dot1Q and IP details – Are you seeing the expected VLAN tags? Are any device dual-homed on multiple networks and could traffic be routed over an unexpected or different interface?
A packet capture can clearly show you what is happening, once you see what is happening you can then ask the question: Why is this happening? e.g.: A device receiving a packet on one VLAN but the response is received on a different VLAN, why is the response appearing on different network than which is was received?
Firewalls for instance allow you see packets getting ‘dropped’ or hitting the ‘bit bucket’, if you capture on both the rx and tx you expect to the see the same Dot1Q information, however if you find packets in the drop log with a different Dot1Q header than expected you can assume asymmetric routing and that may lead you to your root cause.
IP and TCP Options:
IP and TCP options provide an abundance of information about both the endpoints and the conversation:
- IP Length – The size of the packet can help identify packet loss involving MTU and fragmentation related issue.
- Fragmentation – What is the status of the DF-bit? Are overlays in play? How about Jumbo frames? Do you see certain packet size being transmitted from the source but not arriving at the destination? Do you need to move you capture point to identify the source of packet loss?
- Window Size and MSS – Much less a problem these days but does the TCP session have the appropriate TCP MSS and Window size are these setting being manipulated by a load balancer?
- IP Identifier – The IP ID field can be invaluable in the right scenario, especially when troubleshooting switching loops, routing loops, or even software bugs. I’ve done a previous write-up of the IP ID field and therefore won’t be going over the details again but I recommend giving it a quick read before finishing up here.
TCP Flags:
How is TCP behaving? Are you seeing the entire 3-way handshake? Besides capturing at the proper locations you also want to make sure your timing is correct, starting your capture before handshake occurs is vital to understanding the whole picture. The TCP handshake will include items discussed in the previous section such as the Windows Size and MSS, following the window size of a conversation may provide insight into packet loss or buffer issues on one of the endpoints. How about RST packets? It’s important to understand the application, some applications may not be coded properly and rely on RST packets to end connections as opposed to graceful closures with a FIN / FIN+ACK handshake. The last thing you want to do is go down the wrong path and assume something is wrong when it is indeed working as intended. (it may not be optimal but it may be as intended)
Protocol Dependancies
I briefly touched on this earlier in the post, it is good to see the full picture and follow the application / process in its entirety for example:
- When troubleshooting a connection issue are you are capturing the DNS resolution too?
- If you troubleshooting IP Storage or IP File access are you seeing any Kerberos or ticket authentication?
- Are you seeing a successful TLS handshake if you are working with a secure connection?
- In a security-conscience world do you see the RADIUS communication when troubleshooting device onboarding issues?
This post asked a lot of questions, as mentioned at the start this was aimed to provoke that out-of-the-box thinking: Am I troubleshooting this properly? Am I looking at the right pieces? Is there more to this issue than what I am considering? Hopefully some of these questions and examples did just that. I have other Wireshark posts on this blog, many of which are still valid after all these years, some stand-out ones to assist with troubleshooting:
As always, happy hunti…I mean troubleshooting!
As you can tell by my typos, grammar, sprinkled in references, and humor this post was written without the help of Artificial Intelligence (AI). These are my loosely organized ramblings.
